COB LED 12V Controllable BEC module for HEX35

COB LED 12V Controllable BEC module for HEX35 Size:15.6×11.9mm Input:3-6S LiPO Output:5V/12V Current:3A COB module is programmable via Betaflight to turn on/off by channel assigned for LED and camera etc. eg.Configure LED by following setps: solder the led power to FC vbat pads and signal wire to any uart port(rx or tx)note the IO for tx2 Change the red line command setting accordingly ( remember which uart you are using and change that number) resource SERIAL_TX 2 none resource PINIO 1 C12 set pinio_box =40,255,255,255 set pinio_config =1,129,129,129 save Copy the command and paste in CLI Locate USER1 in Betaflight,assign your desired channel and range for control and save.
